• Safety Performance
    Long life lead-acid batteries have a cycle life of about 300 times, with a maximum of 500 times. However, lithium iron phosphate power batteries have a cycle life of over 4000 times(80%DOD).
  • Long life
    Long life lead-acid batteries have a cycle life of about 300 times, with a maximum of 500 times. However, lithium iron phosphate power batteries have a cycle life of over 4000 times(80%DOD).
  • High-capacity
    Long life lead-acid batteries have a cycle life of about 300 times, with a maximum of 500 times. However, lithium iron phosphate power batteries have a cycle life of over 4000 times(80%DOD).
  • Lightweight
    Long life lead-acid batteries have a cycle life of about 300 times, with a maximum of 500 times. However, lithium iron phosphate power batteries have a cycle life of over 4000 times(80%DOD).
  • Environment Protection
    Long life lead-acid batteries have a cycle life of about 300 times, with a maximum of 500 times. However, lithium iron phosphate power batteries have a cycle life of over 4000 times(80%DOD).
  • Over Discharge
    Long life lead-acid batteries have a cycle life of about 300 times, with a maximum of 500 times. However, lithium iron phosphate power batteries have a cycle life of over 4000 times(80%DOD).

Technical Specifications

Electrical

Usable Energy261kWh
Nominal Voltage832 VDC
Nominal Capacity314 Ah
Cycle Life @ 80% DoD> 4000 cycles[1]
Depth of Discharge100% DOD[2]
Operating Voltage Rate702V DC-936V DC

Mechanical

Cell TypeLiFePO4–A grade prismatic cell
Dimensions1000*1400*2500mm
WeightApprox. 2.8t
EnclosureSheet metal
TerminalM8
Colourwhite/customization
LCDYes
BluetoothYes
IP RatingIP54

BMS

Over-charge ProtectionYes
Under Discharge ProtectionYes
Over Current Protection314A
Short Circuit ProtectionYes
Temperature ProtectionYes
Balance FunctionYes

Environmental

Charge Temperature0℃ to 50℃(32℉ to 122℉)
Discharge Temperature-20℃ to 55℃(-4℉ to 131℉)
Storage Temperature-20℃ to 45℃(14℉ to 113℉)
CharactersClean, reliable, efficient, eco-friendly
