Technical Specifications
Electrical
| Usable Energy | 5760 Wh[1] |
| Nominal Voltage | 38.4 VDC |
| Nominal Capacity | 150 Ah |
| Cycle Life @ 80% DoD | > 4000 cycles[1] |
| Depth of Discharge | 100% DOD[2] |
| Operating Voltage Rate | 30V DC-43.8V DC |
Mechanical
| Cell Type | LiFePO4–A grade cell |
| Dimensions | 450*400*240mm (L*W*H) |
| Weight | Approx. 55kg |
| Enclosure | metal |
| Terminal | M8/Positive red/Negative black |
| Colour | Black |
| LCD | Yes |
| Bluetooth | Yes |
Charge
| Charge Mode (CC/CV) | At 0℃~55℃ temperature, charged to 43.8V at a constant current of 20A, then changed continuously with constant voltage of 43.8V until the current was not more than 2A. |
| Charge Current (Recommend ) | ＜75A |
| Charge Current (Maximum) | 75A continuous(25°C） |
| Charge Cut-off Voltage | 43.8 V DC |
Discharge
| Discharge Current (Recommend ) | 75A continuous（25°C） |
| Discharge Current (Maximum) | 150A continuous(25°C） |
| Discharge Cut-off Voltage | 30V |
BMS
| Over-charge Protection | Yes |
| Under Discharge Protection | Yes |
| Over Current Protection | 150A |
| Short Circuit Protection | Yes |
| Temperature Protection | Yes |
| Balance Function | Yes |
Environmental
| Charge Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
| Discharge Temperature | -20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity |
| Storage Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
| Characters | Clean, reliable, efficient, eco-friendly |
